Relè 5V SPST - AZ944-1AH-5DE - ZETTLER
Fai login, così potremo ricontattarti per rispondere
Descrizione
| Contact Material | Silver , Cadmium |
| Mount | Through Hole |
| Number of Pins | 4 |
| Weight | 8 g |
| Coil Current | 40 mA |
| Coil Resistance | 125 Ω |
| Coil Voltage (DC) | 5 V |
| Max Current Rating | 16 A |
| Max Operating Temperature | 95 °C |
| Max Voltage Rating (AC) | 250 V |
| Max Voltage Rating (DC) | 125 V |
| Min Operating Temperature | -40 °C |
| Operate Time | 10 ms |
| Termination | PC Pin |
| Throw Configuration | SPST |
Caratteristiche
Codice fornitore:
AZ944-1AH-5DE
